Google Analytics 通訊協議參數說明 version 2

這是一份非官方的文檔。定義可能在未來發生變化，而不做進一步通知。

Introduction

Google Analytics的測量協議（Measurement Protocol）允許使用者和開發人員直接向Google Analytics端點發送HTTP請求，以測量使用者如何從任何環境/平台進行交互。

我試圖反向工程所有我能夠獲取關於這個即將推出的新協議所使用的參數的詳細信息，以及對照 GTM Tag Template API - getAllEventData() 所對應的參數名稱。

這是一份非官方的文檔。定義可能在未來發生變化，而不做進一步通知。

Parameters Reference

PARAMETER	VALUE TYPE	VALUE	Event Data Name
v	int	Protocol Version	x-ga-protocol_version
tid	string	Measurement ID (G-XXXXXX)	x-ga-measurement_id
gtm	string	GTM Version	x-ga-gtm_version
cid	string	Google Analytics Client ID	x-ga-js_client_id
ul	string	User Language	language
sr	string	Screen Resolution	screen_resolution
_p	int	Random Page Load Hash	x-ga-page_id
_s	int	Current hits counter for the current page load	x-ga-request_count
_dbg	int	Is Debug	x-ga-system_properties.dbg
gcs	string	Google Consent Status (G11-)	x-ga-system_properties.gcs
gcu	string	Google Consent Update	x-ga-system_properties.gcu
gcut	string	Google Consent Update Type	x-ga-system_properties.gcut
gcd	string	Google Consent Default	x-ga-system_properties.gcd
_rnd	string		x-ga-system_properties.rnd

PARAMETER	VALUE TYPE	VALUE	Event Data Name
uid	string	User ID	user_id
sid	string	Session ID	ga_session_id
sct	int	Session Count	ga_session_number
seg	int	Session Engagement, If the current user is engaged in any way, this value will be 1	x-ga-mp2-seg
up.*	string	User Property (String)	x-ga-mp2-user_properties.*
upn.*	int	User Property (Number)	x-ga-mp2-user_properties.*
_fv	int	First Visit	x-ga-system_properties.fv
_ss	int	Session Start	x-ga-system_properties.ss
_nsi	int	New Session ID, If the current user has a GA4 session cookie, this value will be 1	x-ga-system_properties.nsi
_gaz	int	It’s set when a Google Join is created/imported . Google Signals	x-ga-system_properties.gaz
_fplc	string	First Party Linker Cookie, it’s 0 if the FPLC Cookie is not present
sst.uc	string	User Country	x-sst-system_properties.uc
richsstsse

PARAMETER	VALUE TYPE	VALUE	Event Data Name
dl	string	Document Location	page_location
dr	string	Document Referrer	page_referrer
dt	string	Document Title	page_title

Client Hints

PARAMETER	VALUE TYPE	VALUE	Event Data Name
uaa	string	User Agent Architecture	client_hints.architecture
uab	string	User Agent Bitness	client_hints.bitness
uafvl	array	User Agent Full Version List	client_hints.brands
uamb	boolean	User Agent Mobile	client_hints.mobile
uam	string	User Agent Model	client_hints.model
uap	string	User Agent Platform	client_hints.platform
uapv	string	User Agent Platform Version	client_hints.platform_version
uaw	boolean	User Agent WOW64	client_hints.wow64

Event Parmeters

PARAMETER	VALUE TYPE	VALUE	Event Data Name
en	string	Event Name	event_name
ep.*	string	Event Parameter (String)	*
epn.*	int	Event Parameter (Number)	*
_et	int	Engagement Time	engagement_time_msec
_c	int	Is Conversion	x-ga-system_properties.c

Ecommerce Main

PARAMETER	VALUE TYPE	VALUE	Event Data Name
cu	string	Currency Code	currency
pr[0-9]{1,200}	string	An Item Object. It’s a string containing an item details and all it’s params. Check Item Parameters block for more details	items[0-9]

Items

PARAMETER	VALUE TYPE	VALUE	Event Data Name
nm	string	Item Name	item[n].item_name
id	string	Item ID	item[n].item_id
pr	int	Item Price	item[n].price
br	string	Item Brand	item[n].item_brand
ca	string	Item Category 1	item[n].item_category
ca2	string	Item Category 2	item[n].item_category2
ca3	string	Item Category 3	item[n].item_category3
ca4	string	Item Category 4	item[n].item_category4
ca5	string	Item Category 5	item[n].item_category5
qt	int	Item Quantity	item[n].quantity
va	string	Item Variant	item[n].item_variant
cp	string	Coupon	item[n].coupon
ds	int	Discount	item[n].discount
li	string	Item List ID	item[n].item_list_id
ln	string	Item List Name	item[n].item_list_name
lp	int	Index	item[n].index
af	string	Affiliation	item[n].affiliation
lo	string	location ID	item[n].location_id
k[0-9]	string	Item Custom Key	item[n].key
v[0-9]	string	Item Custom Value	item[n].value

Summary

這份文件介紹了Google Analytics Measurement Protocol的參數,其中包括用戶和會話相關參數、共享參數、客戶端提示、事件參數、電子商務主要參數和項目參數。這份文件提供了每個參數的名稱、值類型和值,並將其與Google Tag Manager Tag Template API返回的事件資料對應。
